SATO s86ex - Adjusting the Media Sensors; Adjusting the Media Sensor Automatically

6 Cleaning and Performing Printer Adjustments
255
S84-ex/S86-ex Operator Manual
6.5 Adjusting the Media Sensors
You can check the media sensor condition and adjust the media sensor level for optimum performance.
6.5.1 Adjusting the Media Sensor Automatically
The automatic adjustment procedure for the media sensor is as follows:
1 When the printer is in online mode, press
the LINE button to change the printer
to offline mode.
2 Press the ENTER button.
The printer changes to setting mode menu.
3 Select the SERVICE MODE using the
/// buttons and then press the
ENTER button.
SERVICE MODE setting screen shows.
Note
If password function is enabled, PASSWORD is shown
on the screen instead. Enter the password to continue.
4 Select the SENSOR LEVEL using the
/ buttons and then press the
ENTER button.
SENSOR LEVEL shows on the screen.
5 Select AUTO using the / buttons and
then press the ENTER button.
SENSOR SELECT shows on the screen.
