S84-ex/S86-ex Operator Manual
3.3 Removing the Ribbon
1 Open the top cover.
2 Turn the head lock lever clockwise to unlock the print head.
3 Pull to remove the used ribbon from the
ribbon rewind spindle .
4 Pull to remove the empty core from the
ribbon supply spindle .
You can use this empty core again when you load a
new ribbon roll. Load this empty core onto the
ribbon rewind spindle.
1
2
