8.11.3 External (EXT) Signal Interfaces when RFID Module is Enabled
Standard specification is applied when the RFID module is set to DISABLE. Functions shown by shading
are applied when the RFID module is set to ENABLE.
Pin No. Signal Name
Input/
Output
(25 pins) (14 pins)
Standard Specification
RFID Module Disabled
RFID Module Enabled
1 14 Frame Ground Frame Ground -
2- +5 V +5 V -
3- - - -
4 4 Machine Error Machine Error/RFID Error Output
5 6 Print end signal (PREND) Print end signal (PREND) Output
6 9 Online Online Output
7 - Label Near End Label Near End Input
8 7 Reprint signal (PRIN2) Reprint signal (PRIN2) Input
9- - - -
10 - - - -
11 - OUT_COM OUT_COM -
12 13 +5 V +5 V -
13 12 +24 V +24 V -
14 2 GND GND -
15 2 OUT_COM OUT_COM -
16 3 Ribbon End RFID Tag Error Output
17 1 Paper End Paper End + Ribbon End Output
18 10 Ribbon Near End Ribbon Near End Output
19 - - - -
20 5 Print start signal (PRIN) Print start signal (PRIN) Input
21 11 Label Feed Label Feed Input
22 - - - -
23 - - - -
24 13 IN_COM IN_COM Input
25 - GND GND -
