SATO s86ex - Backfeed Speed; Euro Code

4 Operation and Configuration
130
S84-ex/S86-ex Operator Manual
PREND TYPE 3/4
Select whether to reflect the label feed/stop timing on PREND output
signal in External signal MODE3, 4.
• NORMAL: Do not reflect the label feed/stop timing on PREND output.
• MOTION: Reflect the label feed/stop timing on PREND output.
Note
Shows only if you have installed the optional RFID kit and enabled the
RFID mode.
BACKFEED SPEED
Specify the backfeed speed.
• FAST: Set to a speed of six inches per second.
• NORMAL: Set to a speed of four inches per second.
EURO CODE
Set the European currency symbol to a hex code.
The setting range is from 00 to FF (hexadecimal).
Print
Print End (PREND)
PVHF
Label feeding
Label feeding
Pause
Mode 1
Mode 2
Mode 3
Mode 4
Print
Print End (PREND)
PVHF
Label feeding
Label feeding
Pause
Mode 1
Mode 2
Mode 3
Mode 4
