SATO s86ex - Top View (S84-Ex Printer)

2 Installing the Printer
24
S84-ex/S86-ex Operator Manual
2.2.4 Top View (S84-ex printer)
230 mm (9.1”)
219 mm (8.6”)189 mm (7.4”)
10 mm (0.4”)
51 mm
(2”)
150 mm (5.9”)
223 mm (8.8”) 174 mm (6.85”)174 mm (6.85”) 150 mm (5.9”)150 mm (5.9”)
Americas: Standard/Right Hand
Europe/Asia: Left Hand
