8.13.5 External Signal Interface (EXT)
This interface is designed to connect the printer with other peripherals.
Wiring chart of the 14-pin conversion cable
Basic Specifications
Connector DB 25 pins, female
Supplied with 14-pin conversion cable (Amphenol 14 pins, female)
Signal Levels High-level: +4.2 to +5.0 V
Low-level: +0.0 to +0.7 V
113
1425
DB 25 pins, female
connector (printer)
25 pins 14 pins
114
44
56
69
87
12
13
24
1213
14
2
15
16 3
17 1
18 10
20 5
21 11
SHELL SHELLSHIELD
Amphenol 14 pins,
female connector
DB 25 pins, male
connector
