8 Appendix
365
S84-ex/S86-ex Operator Manual
Connector Pin Specifications
Pin No.
I/O Description
(25 pins) (14 pins)
1 14 - Frame Ground
2 - - Vcc +5 V
3- --
4 4 Output Machine Error:
Outputs a low signal when an error such as the head open error is
detected.
5 6 Output Print end signal (PREND):
Outputs a signal when the media print is completed.
69Output
Online*
3
:
Outputs a low signal when the printer is in offline mode.
7-
Input*
2
Label Near End:
Printer received a label near end signal when a low signal is
detected.
87
Input*
2
Reprint signal (PRIN2):
Prints the previously printed content again when a low signal is
detected.
9- --
10 - - -
11 - - OUT_COM: Ground of peripherals
12 13 - Vcc +5 V
13 12 - +24 V ± 10%
14 2 - GND: Reference Signal Ground
15 2 - OUT_COM: Ground of peripherals
16 3 Output Ribbon End:
Outputs a low signal when the ribbon end is detected.
17 1 Output Paper End:
Outputs a low signal when the paper end is detected.
18 10 Output Ribbon Near End:
Outputs a high signal when the ribbon near end is detected.
19 - - -
20 5
Input*
2
Print start signal (PRIN):
Prints one media when a low signal is detected.
21 11
Input*
2
Label Feed:
Feeds one media when a low signal is detected.
22 - - -
23 - - -
24 13 Input
IN_COM*
1
: Power supply from peripherals
25 - - GND: Reference Signal Ground
