8 Appendix
366
S84-ex/S86-ex Operator Manual
Note
• You can set the external signal type (TYPE1 to TYPE4) for PREND output signal of pin No. 5. Refer to the
EXTERNAL SIGNAL screen of the Advanced Mode menu for details.
• You can set the pin number for input and output through the INPUT SIGNAL/OUTPUT SIGNAL screen of
the Advanced Mode menu.
*1
When using the 14-pin conversion cable, do not connect the power pin to [IN_COM] pin. The [IN COM] pin
is connected to 5 V in cable.
*2
These input signal terminals can be connected to the open collector input devices.
*3
This is online output signal when MODE2 is selected in the EXT 9PIN SELECT screen of the service mode.
The signal outputs the status of the remaining print existing when MODE1 is selected.
