S84-ex/S86-ex Operator Manual
1.1
Printer Orientation
This printer has two types of orientation as below. The media feed direction varies depending on the type
of orientation.
Note
The pictures in this manual show the S84-ex (Americas: Standard/Right Hand, Europe: Left Hand) printer,
unless otherwise stated.
When using the right hand (Americas: Opposite/Left Hand, Europe: Right Hand) model, the picture on the
right shows a symmetrical opposite view of your printer.
When using the S86-ex printer, the dimension of the media compartment is larger.
1
Parts Identification
Media feed direction Media feed direction
Americas: Standard/Right Hand
Europe/Asia: Left Hand
Americas: Opposite/Left Hand
Europe/Asia: Right Hand
