4 Operation and Configuration
122
S84-ex/S86-ex Operator Manual
CALIBRATION COMPLETE/FAILED
This screen shows the result of the automatic sensor adjustment.
• COMPLETE: The automatic adjustment has succeeded.
• FAILED: The automatic adjustment has failed.
Press the ENTER button to proceed to the next screen.
CALIBRATION
Select to exit the automatic sensor adjustment or retry the automatic
sensor adjustment.
• EXIT CALIBRATION: Exit the automatic sensor adjustment.
• RETRY: Retry the automatic sensor adjustment.
SENSOR LEVEL I-MARK(E)
Shows the current level (Emission) of the I-mark sensor on the upper part
of the screen.
This offset determines how soon the sensor will respond to an incoming
I-mark. The adjustment range is from 1 to 3 and is shown on the bottom
line of the screen.
SENSOR LEVEL I-MARK(R)
Shows the current level (Reception) of the I-mark sensor on the upper part
of the screen.
This offset determines how soon the sensor will respond to an incoming
I-mark. The adjustment range is from 0 to 127 and is shown on the bottom
line of the screen.
