4 Operation and Configuration
179
S84-ex/S86-ex Operator Manual
TEST PRINT MODE
Select the test print contents.
• CONFIGURATION: Print the configuration settings of the printer.
• BARCODE: Print the barcodes installed in this printer.
• HEAD CHECK: Print the head check pattern of the selected media size
area.
• MEMORY: Print the contents of the memory in this printer.
• FONT: Print the contents of the fonts installed in this printer.
• CONFIGURE LIST: Print the configure list of the printer.
• FACTORY: Perform the factory test print.
• WLAN: Print the wireless LAN settings of the printer.
Note
WLAN shows only if a wireless LAN unit is installed.
TEST PRINT SIZE
Set the width of the test print in 1 cm steps.
The setting range varies depending on the model as follows:
Note
Shows only if TEST PRINT MODE is set to CONFIGURATION, BARCODE
or HEAD CHECK.
TEST PRINT SIZE
Select the width of the test print from LARGE or SMALL.
The available width varies depending on the model as follows:
Note
Shows only if TEST PRINT MODE is set to FACTORY or WLAN.
Model Name Setting Range
(cm)
Default
Value (cm)
S84-ex 04-10 10
S86-ex 05-16 16
Model Name LARGE (cm) SMALL (cm)
S84-ex 10 4
S86-ex 16 5
