6 Cleaning and Performing Printer Adjustments
260
S84-ex/S86-ex Operator Manual
13
Press the ENTER button to confirm the setting and proceed to slice level adjustment
screen.
Note
If you are having difficulties in adjusting the sensor level properly, clean the media sensor portion. If the
problem persists, contact your SATO reseller or technical support center to replace the media sensor.
14
Press the / buttons to change the
SLICE LEVEL and then press the
ENTER button.
The slice level can be set to 0.0 V, or from 0.3 V to
2.9 V. (adjustable in increments of 0.1 V)
If you set the SLICE LEVEL to 0.0 V, the printer sets
the slice level automatically.
15
If you completed with I-mark sensor level
adjustment, press the FUNCTION
button to return to the SERVICE MODE
menu. Otherwise, continue with the Gap
sensor level adjustment.
Proceed to step 2 of Section 6.5.3 Adjusting the
Gap Sensor Level Manually.
