8 Appendix
296
S84-ex/S86-ex Operator Manual
HEAD CHECK DISABLE Yes Yes
HEAD CHECK NORMAL (When HEAD CHECK is
enabled)
Yes Yes
HEAD CHECK MODE ALL (When HEAD CHECK is enabled) Yes Yes
HEAD CHECK PAGE NO. 000001 (When CHECK PAGE is
selected)
Yes Yes
EXTERNAL SIGNAL SETTING NO - -
EXTERNAL SIGNAL ENABLE Yes Yes
EXTERNAL SIGNAL TYPE4 Yes Yes
EXTERNAL REPRINT DISABLE Yes Yes
CONTINUOUS PRINT DISABLE Yes Yes
ENHANCED REPRINT DISABLE Yes Yes
I/O SIGNAL SETTING NO - -
INPUT SIGNAL
PRINT START 20Pin Yes Yes
REPRINT 8Pin Yes Yes
LABEL NEAR 7Pin Yes Yes
FEED 21Pin Yes Yes
OUTPUT SIGNAL
PAPER END 17Pin Yes Yes
RIBBON END 16Pin Yes Yes
MACHINE ERR 4Pin Yes Yes
PRINT END 5Pin Yes Yes
ONLINE 6Pin Yes Yes
RIBBON NEAR 18Pin Yes Yes
DECIDED? NO - -
I/O SIGNALS INITIALIZE NO - -
ZERO SLASH YES Yes Yes
AUTO ONLINE YES Yes Yes
PRINT OFFSET V:+0000 H:+0000 Yes Yes
HEAD DOT DENSITY 300,
only for S84-ex/S86-ex (12 dots/mm)
Yes Yes
Setting Item Initial Value
Default
(User)
Default
(Shipping)
