Scania CV AB 2011, Sweden
01:03-02
Left-hand side:
Note: When removing the gearbox, engine
support 99 318 must be used to support the
engine.
Comments
17 Detach The flexible hose for the charge air pipe.
18 Detach The AC compressor and move it aside. 4 bolts.
19 Detach The compressor feed pipe.
20 Detach The water heater hose. Only on vehicles equipped with a
water heater.
21 Detach The ground connection.
22 Detach The fuel pipes.
23 Detach The oil filler hose.
24 Detach The oil dipstick.
25 Detach The starter motor ground connection.
26 Detach The pressure regulator pipe. Detach at the compressor.
27 Detach The positive starter motor cable.
28 Detach The hydraulic pump and move it aside. 5 bolts in the flange.
29 Remove The gearbox. Refer to Group 5.
100329
99 318
Engine assembly
