6
©
Scania CV AB 2011, Sweden
01:03-02
Removing the engine
Comments
1 Drain Oil and coolant.
2 Remove The battery cover and detach the
negative cable.
3 Remove The protective casing.
4 Remove Connectors 13 (C2) and 14 (C188). Connector 14 (C188) is only fitted
on vehicles without a coordinator.
5 Disconnect The positive and negative cables.
6 Remove The clamps to release electrical cables
13 and 14.
7 Tilt the cab according to instructions, refer to Group 18.
8 Remove The mudguards.
Engine assembly
