Scania DC11 - Renewing the Rear Crankshaft Seal

01:03-02
©
Scania CV AB 2011, Sweden
63
Renewing the rear crankshaft seal
Special tools
1 Remove the flywheel according to the
section Removing the flywheel.
2 Remove the crankshaft seal using a
screwdriver. Take care not to scratch the
sealing surfaces on the crankshaft and the
flywheel housing. Alternatively a self-
tapping screw can be screwed into the
crankshaft seal so that the crankshaft seal
can be pulled out with a slide hammer.
Number Denomination Illustration Tool board
99 410 Assembly tool D5
99 058 Drift (used together with 99 410
when renewing 185 mm
crankshaft seal)
D7
99 410
116 247
156 015
01_1356
Cylinder block
