Scania DC11 - Removing the Camshaft

01:03-02
©
Scania CV AB 2011, Sweden
119
Removing the camshaft
1 Remove the flywheel according to the
section Removing the flywheel.
2 Remove the flywheel housing according to
the section Removing the flywheel housing.
3 Remove rocker arms, pushrods and valve
bridges.
4 Remove the camshaft gear.
5 Remove the intermediate gear according to
the section Removing the intermediate gear
and bolts for the guide flange.
6 Remove the timing gear plate.
7 Remove the camshaft covers.
01_1370
8 Remove the roller tappets.
Note: Mark the roller tappets because they must
be refitted in the same positions.
9 Pull out the camshaft backwards. Take care
not to damage the cams and bearings.
01_1371
Timing gear
