26
©
Scania CV AB 2011, Sweden
01:03-02
Removing the cylinder head (engines with injection pump)
Special tools
1 Remove the pressure pipes using socket
99 310.
2 Detach the intake manifold and remove the
fuel return pipe.
3 Remove the cooling system bleed pipe.
4 Remove the heat shields on the exhaust
manifold and remove the exhaust manifold.
Number Denomination Illustration Tool board
99 074 Impact setting tool D1
99 079 Extractor for injector D1
99 308 Sleeve for injector -
99 310 Socket -
99 079
113 009
00 1540
99 308
100331
Cylinder head
