Scania DC11 - Checking Engine Injectors

01:03-02
©
Scania CV AB 2011, Sweden
27
Note: All the valve mechanism components
must be refitted in their original positions.
Therefore, mark the parts as they are removed.
5 Remove the top part of the rocker cover.
6 Remove the shaft, rocker arms, bearing
brackets and pushrods.
7 Remove the lower part of the rocker cover.
01_1344
8 Undo the injector nut using socket 99 308.
01 1345
99 308
9 Pull out the injectors with tools 99 079 and
99
074.
10 Remove the cylinder head. Mark the
cylinder heads if more than one is being
removed at the same time.
01 1346
99 074
99 079
Cylinder head
