Scania CV AB 2011, Sweden
01:03-02
Removing the cylinder head (engines with PDE unit injectors)
1 Open the bleed nipple and drain the fuel
system by undoing the banjo screw on the
back of the fuel manifold.
!
WARNING!
The fuel system must be empty or fuel
may run down into the cylinders, which
will result in a great risk of liquid
slugging.
If fuel runs into the combustion
chamber, it must be removed
immediately using a pump.
2 Clean the rocker cover and the area around
it.
3 Remove the top part of the rocker cover.
108 036
4 Relieve the pressure on the valves by
undoing the bolts on the rocker arm shaft
alternately.
120513
4
Cylinder head
