Scania DC11 - Mounting the Engine in an Engine Stand

20
©
Scania CV AB 2011, Sweden
01:03-02
Mounting the engine in an engine stand
Engines with injection pump
Remove: Pos.
Fuel filter A
Injection pump F
Bracket E
Starter motor D
Required brackets
Engines with PDE unit injectors
Remove: Pos.
Fuel filter A
Control unit B
Compressor C
Starter motor D
Required brackets
Engines with HPI unit injectors
Securely bolt the engine to the engine stand as
illustrated. Use tool 99 331.
Remove: Pos.
Fuel filter A
Control unit B
Compressor C
Starter motor D
Feed pump G
Engine assembly
