14
©
Scania CV AB 2011, Sweden
01:03-02
Fitting the engine
Tightening torques
Left-hand side:
Engine bracket bolts M14: 47 Nm
M16: 130 Nm+90°
V-clamp for the charge air cooler 8 Nm
1 Lift the engine so that the engine brackets are approx. 10 mm over the engine cushions.
2 Position the bolts and lower the engine so that it rests on the engine cushions and engine
supports 99
318. Tightening torques: M14 bolts, 47 Nm and M16 bolts, 130 Nm+90°.
3 Fit the gearbox. Refer to Group 5.
Comments
4 Fit The hydraulic pump. Fit a new gasket.
5 Fit The positive starter motor cable.
6 Fit The pressure regulator pipe. At the compressor.
7 Fit The starter motor ground connection.
8 Fit The oil dipstick.
9 Fit The oil filler hose.
10 Fit The fuel pipes. RV= upper, RA= lower.
11 Fit The ground connection. At the compressor.
12 Fit The water heater hose.
13 Fit The compressor feed pipe.
14 Fit The AC compressor.
15 Fit The flexible hose for the charge air pipe. Tightening torque, 8 Nm.
Engine assembly
