Scania DC11 - Detailed Maintenance Schedule

01:03-02
©
Scania CV AB 2011, Sweden
13
IMPORTANT! The lifting eyes are designed to
cope with a maximum inclination angle of 30°,
when lifting an engine with the gearbox removed.
For engines without the gearbox removed, the
maximum angle is 20°.
Engine assembly
32 Remove the bolts in the engine brackets
and lift out the engine.
01_1399
