01:03-02
©
Scania CV AB 2011, Sweden
129
Renewing the O-rings
1 Remove the side cover and oil cooler from
the cylinder block.
2 Remove the 4 bolts securing the oil cooler
to the side cover.
3 Remove the oil cooler.
4 Renew the O-rings, 4 off.
5 Fit the oil cooler insert and bolt it into place
in the cover to 26
Nm.
6 Bolt the side cover into place in the
cylinder block.
Lubrication system
