16
©
Scania CV AB 2011, Sweden
01:03-02
Right-hand side:
Comments
16 Fit The exhaust pipe.
17 Fit The air hose for the exhaust brake
cylinder.
18 Fit The radiator water hoses. Only one hose is illustrated.
19 Fit The flexible hose for the charge air
cooler.
Tightening torque, 8 Nm.
20 Fit The turbocharger induction pipe. Tightening torque, 10 Nm, must
be applied at max. 100 rpm.
21 Fit The compressor air pipe and the
crankcase ventilation hose on the
induction pipe.
22 Fit The poly-V-belt.
23 Route Cables 13 and 14 to the front of the cab.
Engine assembly
