8
©
Scania CV AB 2011, Sweden
01:03-02
Right-hand side:
Comments
9 Pull through the detached cable harnesses and place them on the engine.
10 Remove The turbocharger induction pipe. The compressor air pipe and the
crankcase ventilation hose must be
detached from the induction pipe.
11 Cover the air filter.
12 Detach The radiator water hoses. The number of hoses varies
depending on the design. Only one
hose is illustrated.
13 Detach The flexible hose for the charge air pipe.
14 Lift off The poly-V-belt. Only on vehicles with air
conditioning.
15 Detach The air hose for the exhaust brake
cylinder.
16 Remove The exhaust pipe.
Engine assembly
