4.35
Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
Control Logic
Relay Word Bits
49 LB9 Local Bit 9 asserted (all but SEL-387-0 Relay)
LB10 Local Bit 10 asserted (all but SEL-387-0 Relay)
LB11 Local Bit 11 asserted (all but SEL-387-0 Relay)
LB12 Local Bit 12 asserted (all but SEL-387-0 Relay)
LB13 Local Bit 13 asserted (all but SEL-387-0 Relay)
LB14 Local Bit 14 asserted (all but SEL-387-0 Relay)
LB15 Local Bit 15 asserted (all but SEL-387-0 Relay)
LB16 Local Bit 16 asserted (all but SEL-387-0 Relay)
53 49A01A RTD1A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T01A RTD1A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A02A RTD2A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T02A RTD2A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A03A RTD3A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T03A RTD3A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A04A RTD4A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T04A RTD4A trip picked up (SEL-387-5 and SEL-387-6 Relays)
54 49A05A RTD5A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T05A RTD5A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A06A RTD6A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T06A RTD6A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A07A RTD7A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T07A RTD7A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A08A RTD8A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T08A RTD8A trip picked up (SEL-387-5 and SEL-387-6 Relays)
55 49A09A RTD9A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T09A RTD9A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A10A RTD10A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T10A RTD10A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A11A RTD11A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T11A RTD11A trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A12A RTD12A alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T12A RTD12A trip picked up (SEL-387-5 and SEL-387-6 Relays)
56 49A01B RTD1B alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T01B RTD1B trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A02B RTD2B alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T02B RTD2B trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A03B RTD3B alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T03B RTD3B trip picked up (SEL-387-5 and SEL-387-6 Relays)
49A04B RTD4B alarm picked up (SEL-387-5 and SEL-387-6 Relays)
49T04B RTD4B trip picked up (SEL-387-5 and SEL-387-6 Relays)
Table 4.10 Relay Word Bit Definitions (Sheet 11 of 12)
Row Bit Definition
