E.8
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Compressed ASCII Commands
SEL-387-6 Relay
The relay responds:
<STX>
"LLLL","LLLL","LLLL","LLLL","LLLL","LLLL","LLLL","LLLL","yyyy"<CR>
x,x,x,x,x,x,x,x,"yyyy"<CR>
<ETX>
SEL-387-6 Relay
CASCII Command
Display the SEL-387 Compressed ASCII configuration message by sending:
CAS <Enter>
SEL-387-5 Relays send information on the CST, CBR, CHI, CEV, CEV C,
CEV S64 R, and CTA Compressed ASCII commands. SEL-387-6 Relays
send the same information as SEL-387-5 Relays plus information on the
CTH, CTH D 1, CTH D 2, CTH D 3, CTH H 1, CTH H 2, CTH H3, and
CTH T Compressed ASCII thermal commands. A sample SEL-387-6 Relay
response is shown below:
<STX>
"CAS",15,"yyyy"<CR>
"CST",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"26H","IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","+5V_PS","+5V_REG","-5V_REG","+12V_PS","-12V_PS","+15V_PS",
"-15V_PS","TEMP","RAM","ROM","A/D","CR_RAM","EEPROM","IO_BRD","yyyy"<CR>
"1D","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S"
,"9S",
"9S","9S","9S","9S","9S","9S","9S","9S","9S","yyyy"<CR>
"CBR",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"19H","BREAKER","INT_TRIPS","IAW","IBW","ICW","EXT_TRIPS","IAW","IBW","ICW","POLE1",
"POLE2","POLE3","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC",
"yyyy"<CR>
"4D","I","I","F","F","F","I","F","F","F","I","I","I","I","I","I","I","I","I","I","yy
yy"<CR>
"CHI",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"11H","REC_NUM","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","EVENT",
"GROUP","TARGETS","yyyy"<CR>
"80D","I","I","I","I","I","I","I","I","7S","I","52S","yyyy"<CR>
"CEV",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"5H","FREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","EVENT","yyyy"<CR>
"1D","F","I","I","F","7S","yyyy"<CR>
"15H","IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","VDC","TRIG","NAMES OF ELEMENTS IN ALL RELAY WORD ROWS",
"yyyy"<CR>
(Continued on next page)
"60D","F","F","F","F","F","F","F","F","F","F","F","F","F","1S","96S","yyyy"<CR>
where:
LLLL = the labels for the given target.
x = 0 or 1 corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the hex checksum for
the line.
