5.25

Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay

Metering and Monitoring

Status Monitor

Table 5.4 Self-Test Alarm Limits

Self-Test Warning Limits Failure Lim its

Channel Offset 30 mVdc NA

+5 V Power Supply 4.80/5.20 Vdc 4.65/5.40 Vdc

+5 V Regulated 4.75/5.20 Vdc 4.50/5.40 Vdc

–5 V Regulated –4.75/–5.25 Vdc –4.50/v5.40 Vdc

+12 V Power Supply 11.50/12.50 Vdc 11.20/14.00 Vdc

–12 V Power Supply –11.50/–12.50 Vdc –11.20/–14.00 Vdc

+15 V Power Supply 14.40/15.60 Vdc 14.00/16.00 Vdc

–15 V Power Supply –14.40/–15.60 Vdc –14.00/–16.00 Vdc

Temperature –40/+85°C –50/+100°C

RAM NA Cannot READ/WRITE

Flash ROM NA Bad Checksum

A/D NA Slow Conversion

Critical RAM NA Bad Checksum

EEPROM NA Bad Checksum

IO_BRD NA Incorrect Interface Board Value
