Schweitzer Engineering SEL-387-0 - Table 9.4 Digital Event Report Column Description; Figure 9.3 Example Digital Event Report

9.8
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Event Reports and SER
Standard 15-, 30-, or 60-Cycle Event Reports
XFMR 1 Date: 02/28/97 Time: 06:28:38.888
STATION A
FID=SEL-387-R102-V#####-D970226
Overcurrent Elements
Winding 1 Winding 2 Winding 3 Winding 4
50 51 50 51 50 51 50 51 51 DC TRP DEM OUT IN
PPABCNNQQPNQ PPABCNNQQPNQ PPABCNNQQPNQ PPABCNNQQPNQ PNPN PPNNQQ
123331212 123331212 123331212 123331212 CCCC 13 135 131313 1357 135
444 444 444 444 1122 24 24 242424 246A 246
[1]
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
[2]
............ ............ ............ ............ .... .. ... ...... .... ...>
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...*
.
.
.
[15]
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
............ ............ ............ ............ .... .. ... ...... .... ...
Event: TRIP1 TRIP2 TRIP3 TRIP4 TRIP5
Targets: TRIP INST 87-1 87-2 87-3 50 51 A B C N W1 W2 W3 W4
Winding 1 Currents (A Sec), ABC: 123.4 123.4 123.4
Winding 2 Currents (A Sec), ABC: 123.4 123.4 123.4
Winding 3 Currents (A Sec), ABC: 123.4 123.4 123.4
Winding 4 Currents (A Sec), ABC: 123.4 123.4 123.4
Figure 9.3 Example Digital Event Report
The trigger row includes a > character following immediately after the last
digital column to indicate the trigger point. A
* character following
immediately after the last digital column denotes that the designated row was
used for the Event Summary currents. The
* character takes precedence over
the
> character when both conditions occur for the same row.
Table 9.4 summarizes the digital event report columns.
Table 9.4 Digital Event Report Column Description (Sheet 1 of 3)
Column
Heading
Symbol Definition
All
.
All indication deasserted
Winding 1
50P1
1
T
50P11 asserted
50P11T asserted
Winding 1
50P2
2
50P12 asserted
Winding 1
50A34
3
4
b
50A13 asserted
50A14 asserted
50A13 and 50A14 asserted
Winding 1
50B34
3
4
b
50B13 asserted
50B14 asserted
50B13 and 50B14 asserted
Winding 1
50C34
3
4
b
50C13 asserted
50C14 asserted
50C13 and 50C14 asserted
Winding 1
50N1
1
T
50N11 asserted
50N11T asserted
Winding 1
50N2
2
50N12 asserted
