E.3
Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
Compressed ASCII Commands
SEL-387-0, -5 Relay
If a Compressed ASCII request is made for data that are not available, (e.g.,
the history buffer is empty or invalid event request), the relay responds with
the following message:
<STX>"No Data Available","0668"<CR><ETX>
SEL-387-0, -5 Relay
CASCII Command
Display the SEL-387 Compressed ASCII configuration message by sending:
CAS <Enter>
The SEL-387-5 sends (the SEL-387-0 sends a similar response):
<STX>
"CAS",7,"yyyy"<CR>
"CST",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"26H","IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","+5V_PS","+5V_REG","-5V_REG","+12V_PS","-12V_PS","+15V_PS",
"-15V_PS","TEMP","RAM","ROM","A/D","CR_RAM","EEPROM","IO_BRD","yyyy"<CR>
"1D","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S"
,"9S",
"9S","9S","9S","9S","9S","9S","9S","9S","9S","yyyy"<CR>
"CBR",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"19H","BREAKER","INT_TRIPS","IAW","IBW","ICW","EXT_TRIPS","IAW","IBW","ICW","POLE1",
"POLE2","POLE3","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC",
"yyyy"<CR>
"4D","I","I","F","F","F","I","F","F","F","I","I","I","I","I","I","I","I","I","I","yy
yy"<CR>
"CHI",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"11H","REC_NUM","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","EVENT",
"GROUP","TARGETS","yyyy"<CR>
"80D","I","I","I","I","I","I","I","I","7S","I","52S","yyyy"<CR>
"CEV",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"5H","FREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","EVENT","yyyy"<CR>
"1D","F","I","I","F","7S","yyyy"<CR>
"15H","IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","VDC","TRIG","NAMES OF ELEMENTS IN ALL RELAY WORD ROWS",
"yyyy"<CR>
"60D","F","F","F","F","F","F","F","F","F","F","F","F","F","1S","96S","yyyy"<CR>
"CEV C",1,"yyyy"<CR>
"1H","FID","yyyy"<CR>
"1D","40S","yyyy"<CR>
"7H","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
"1D","I","I","I","I","I","I","I","yyyy"<CR>
"5H","FREQ","SAM/CYC_A","SAM/CYC_D","NUM_OF_CYC","EVENT","yyyy"<CR>
"1D","F","I","I","F","7S","yyyy"<CR>
"15H","IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","VDC","TRIG","NAMES OF ELEMENTS IN ALL RELAY WORD ROWS",
"yyyy"<CR>
"120D","F","F","F","F","F","F","F","F","F","F","F","F","F","1S","96S","yyyy"<CR>
(Continued on next page)
