Schweitzer Engineering SEL-387-0 - SEL-387-0, -5, -6 Relay Settings Sheets Example

Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
Date _______________ SET.1 of 36SEL-387-0, -5, -6 Relay Settings Sheets Example
Group Settings (SET Command)
SEL-387-0, -5, -6 Relay
Settings Sheets Example
Group Settings (SET Command)
Configuration Settings
Relay Identifier (39 Characters)
RID = XFMR 1
Terminal Identifier (59 Characters)
TID = STATION A
Enable Winding 1 in Differential Element (Y, N, Y1)
E87W1 = Y
Enable Winding 2 in Differential Element (Y, N, Y1)
E87W2 = Y
Enable Winding 3 in Differential Element (Y, N, Y1)
E87W3 = Y
Enable Winding 4 in Differential Element (Y, N, Y1)
E87W4 = N
Enable Winding 1 O/C Elements and Dmd Thresholds (Y, N)
EOC1 = Y
Enable Winding 2 O/C Elements and Dmd Thresholds (Y, N)
EOC2 = Y
Enable Winding 3 O/C Elements and Dmd Thresholds (Y, N)
EOC3 = Y
Enable Winding 4 O/C Elements and Dmd Thresholds (Y, N)
EOC4 = N
Enable Combined O/C Elements (Y, N)
EOCC = N
Enable Thermal Element (Y, N) (SEL-387-6 Relay only)
ETHER = Y
Enable RTDA Element (Y, N)
(SEL-387-5 and SEL-387-6 Relays only)
E49A = N
Enable RTDB Element (Y, N)
(SEL-387-5 and SEL-387-6 Relays only)
E49B = N
Enable SEL
OGIC
®
Control Equations Set 1 (Y, N) ESLS1 = N
Enable SEL
OGIC Control Equations Set 2 (Y, N) ESLS2 = N
Enable SEL
OGIC Control Equations Set 3 (Y, N) ESLS3 = N
General Data
Winding 1 CT Connection (D, Y) W1CT = Y
Winding 2 CT Connection (D, Y)
W2CT = Y
Winding 3 CT Connection (D, Y)
W3CT = Y
Winding 4 CT Connection (D, Y)
W4CT = Y
