G.8
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Distributed Network Protocol
DNP3 Documentation
Data Map
The following is the default object map supported by the SEL-387 (see
Appendix A: Firmware and Manual Versions).
60 2 Class 1 Data 1,20,21 6,7,8
60 3 Class 2 Data 1,20,21 6,7,8
60 4 Class 3 Data 1,20,21 6,7,8
70 1 File Identifier
80 1 Internal Indications 2 0,1 index = 7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary-Coded Decimal
101 2 Medium Packed Binary-Coded Decimal
101 3 Large Packed Binary-Coded Decimal
112 All Virtual Terminal Output Block 2 6
113 All Virtual Terminal Event Data 1,20,21 6 129,130 17,28
No object 13,14,23
a
Default.
Table G.4 SEL-387 Relay DNP Object Table (Sheet 4 of 4)
Object Request (supported) Response (may generate)
Obj. Var. Description
Function
Codes
(decimal)
Qualifier
Codes (hex)
Function
Codes
(decimal)
Qualifier Codes
(hex)
Table G.5 SEL-387 Relay-Wye/Delta DNP Data Map (Sheet 1 of 4)
DNP
Object Type
Index Description
01,02 000–799 Relay Word, where OCA is 0 and TRIP1 is 319.
01,02 800–1599 Relay Word from the SER,
encoded same as inputs 000–799 with 800 added.
01,02 1600–1615 Relay front-panel targets, where 1615 is A,
1608 is W4, 1607 is EN, and 1600 is 51.
01,02 1616 Relay Disabled.
01,02 1617 Relay diagnostic failure.
01,02 1618 Relay diagnostic warning.
01,02 1619 New relay event available.
01,02 1620 Settings change or relay restart.
10,12 00–15 Remote bits RB1–RB16.
10,12 16 Pulse Open breaker 1 command OC.
