DNP3 Documentation
30 2 16-Bit Analog Input 1 0,1,6,7,8 129 0,1,7,8
30 3 32-Bit Analog Input Without Flag 1 0,1,6,7,8 129 0,1,7,8
30 4
a
16-Bit Analog Input Without Flag 1 0,1,6,7,8 129 0,1,7,8
31 0 Frozen Analog Input-All Variations
31 1 32-Bit Frozen Analog Input
31 2 16-Bit Frozen Analog Input
31 3 32-Bit Frozen Analog Input With Time of
Freeze
31 4 16-Bit Frozen Analog Input With Time of
Freeze
31 5 32-Bit Frozen Analog Input Without Flag
31 6 16-Bit Frozen Analog Input Without Flag
32 0 Analog Change Event-All Variations 1 6,7,8
32 1 32-Bit Analog Change Event Without Time 1 6,7,8 129 17,28
32 2
a
16-Bit Analog Change Event Without Time 1 6,7,8 129,130 17,28
32 3 32-Bit Analog Change Event With Time 1 6,7,8 129 17,28
32 4 16-Bit Analog Change Event With Time 1 6,7,8 129 17,28
33 0 Frozen Analog Event-All Variations
33 1 32-Bit Frozen Analog Event Without Time
33 2 16-Bit Frozen Analog Event Without Time
33 3 32-Bit Frozen Analog Event With Time
33 4 16-Bit Frozen Analog Event With Time
40 0 Analog Output Status-All Variations 1 0,1,6,7,8
40 1 32-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
40 2
a
16-Bit Analog Output Status 1 0,1,6,7,8 129 0,1,7,8
41 0 Analog Output Block-All Variations
41 1 32-Bit Analog Output Block 3,4,5,6 17,28 129 echo of request
41 2 16-Bit Analog Output Block 3,4,5,6 17,28 129 echo of request
50 0 Time and Date-All Variations
50 1 Time and Date 1,2 7,8 index = 0 129 07, quantity = 1
50 2 Time and Date With Interval
51 0 Time and Date CTO-All Variations
51 1 Time and Date CTO
51 2 Unsynchronized Time and Date CTO 07, quantity = 1
52 0 Time Delay-All Variations
52 1 Time Delay Coarse
52 2 Time Delay Fine 129 07, quantity = 1
60 0 All Classes of Data 1,20,21 6
60 1 Class 0 Data 1 6
Table G.4 SEL-387 Relay DNP Object Table (Sheet 3 of 4)
Object Request (supported) Response (may generate)
Obj. Var. Description
Function
Codes
(decimal)
Qualifier
Codes (hex)
Function
Codes
(decimal)
Qualifier Codes
(hex)
