7.6

SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601

Serial Port Communications and Commands

Establish Communication

SEL-387 to

SEL Communications

Processor

Table 7.3 Serial Communications Port Pin Function Definitions

Pin Function Definition

N/C No Connection

+5 Vdc 5 Vdc Power Connection

RXD, RX Receive Data

TXD, TX Transmit Data

+(–)IRIG-B IRIG-B Time-Code Input

GND Ground

SHIELD Shielded Ground

RTS Request to Send

CTS Clear to Send

DCD Data Carrier Detect

DTR Data Terminal Ready

DSR Data Set Ready

9-Pin Male

"D" Subconnector "D" Subconnector

9-Pin Male

RXD TXD

TXD RXD

IRIG+ IRIG+

GND GND

IRIG- IRIG-

RTS

CTS

RTS

Func.

SEL-387 Relay

Cable C273A

9-Pin Male

"D" Subconnector

9-Pin Male

RXD TXD

TXD RXD

GND GND

RTS RTS

CTS CTS

Func.

SEL-2032,

SEL-2030, or SEL-2020

SEL-2032,

SEL-2030, or SEL-2020

SEL-387 Relay

Cable C272A
