SEL-387 Relay Command Summary
Access Level 0
Commands
The only thing that can be done at Access Level 0 is to go to Access Level 1. The screen prompt is: =
ACC Enter Access Level 1. If the main board password jumper (JMP6A) is not in place, the relay prompts for the entry
of the Access Level 1 password in order to enter Access Level 1.
QUI Quit. Returns to Access Level 0. Returns front-panel LEDs to the default targets.
Access Level 1
Commands
The Access Level 1 commands primarily allow the user to look at information
(e.g., settings, metering, etc.), but not to change it. The screen prompt is: =>
2AC Enter Access Level 2. If the main board password jumper (JMP6A) is not in place, the relay prompts for the entry
of the Access Level 2 password in order to enter Access Level 2.
BAC Enter Access Level B. If the main board password jumper (JMP6A) is not in place, the relay prompts for the
entry of the Access Level B password in order to enter Access Level B.
BRE Breaker report shows trip counters, trip currents, and wear data for up to four breakers.
CEV n Show compressed winding event report number n, at 1/4-cycle resolution.
Attach DIF for compressed differential element report, at 1/4-cycle resolution.
Attach R for compressed raw winding data report, at 1/16-cycle resolution.
Attach Sm for 1/m-cycle resolution (m = 4 or 8 for filtered data; m = 4, 8, 16, 32, or 64 for raw data).
DAT Show date presently in the relay.
DAT m/d/y Enter date in this manner if Date Format setting DATE_F = MDY.
DAT y/m/d Enter date in this manner if Date Format setting DATE_F = YMD.
EVE n Show standard event report number n, with 1/4-cycle resolution.
Attach S8 for 1/8-cycle resolution.
EVE D n Show digital data event report number n, with 1/4-cycle resolution.
Attach S8 for 1/8-cycle resolution.
EVE DIF1 n Show differential element 1 event report number n, with 1/4-cycle resolution.
Attach S8 for 1/8-cycle resolution.
EVE DIF2 n Show differential element 2 event report number n, with 1/4-cycle resolution.
Attach S8 for 1/8-cycle resolution.
EVE DIF3 n Show differential element 3 event report number n, with 1/4-cycle resolution.
Attach S8 for 1/8-cycle resolution.
EVE R n Show raw analog data event report number n, with 1/16-cycle resolution.
Attach Sm for 1/m-cycle resolution (m = 4, 8, 32, 64).
EVE T Show event summary.
GRO Display active setting group number.
HIS n Show brief summary of the n latest event reports.
HIS C Clear the brief summary and corresponding standard event reports.
ID Display variety of identification and configuration information about the relay.
INI INITIO
command reports the number and type of I/O boards in the relay.
IRI Force synchronization attempt of internal relay clock to IRIG-B time-code input.
MET k Display metering data, in primary amperes. Enter number k to scroll metering k times on screen.
MET D k Display demand metering data, in primary amperes. Enter number k to scroll metering k times on screen.
MET DIF k Display differential metering data, in multiples of TAP. Enter number k to scroll metering k times on screen.
