Section 6
Setting the Relay
Overview
Change or view settings with the SET and SHOWSET serial port commands
and the front-panel {SET} pushbutton. Table 6.1 lists the serial port SET
commands.
View settings with the respective serial port SHOWSET commands (SHO,
SHO G, SHO R, SHO P). See discussion of SHO (Show Group 1—6
Settings) on page 7.29. Settings Sheets are located at the end of this section.
Settings Changes Via the Front Panel
The relay front-panel {SET} pushbutton provides access to the Relay, Global,
and Port settings only. Thus, the corresponding Relay, Global, and Port
settings sheets that follow in this section can also be used when making these
settings via the front panel. Refer to Figure 8.8 for information on front-panel
settings.
Table 6.1 Serial Port SET Commands
Command Settings Type Description
SET n Relay Overcurrent elements for settings group n
(n = 1, 2, 3, 4, 5, 6).
SET G Global Battery and breaker monitors, etc.
SET R SER Sequential Events Recorder trigger conditions.
SET P n Port Serial port settings for Serial Port n (n = 1, 2, 3, or 4).
