9.11

Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay

Event Reports and SER

Standard 15-, 30-, or 60-Cycle Event Reports

Use the EVENT DIF command to retrieve differential event reports. There

are several options to customize the report format. The general command

format is:

EVE DIFz [n, Sx, Ly[–[w]]] (parameters in [ ] are optional)

Refer to Figure 9.4 for an example differential event report. This example

event report displays rows of information each quarter-cycle and was retrieved

with the EVE DIF1 <Enter> command.

XFMR 1 Date: 02/28/97 Time: 06:28:38.888

STATION A

FID=SEL-387-R102-V#####-D970226

Differential Set 1 Set 2 Set 3

Differential Quantities 87 87B HB TR TRP LT LT OUT IN

Multiples of TAP R HE 135 VVVV13 VVVV13 VVVVVVVV 1357 135

IOP1 IRT1 I1F2 I1F5 U123 123 123 5F 24 123424 123424 12345678 246A 246

[1]

123.12 123.12 123.12 123.12 .... ... ... .. ... ...... ...... ........ .... ...

[2]

123.12 123.12 123.12 123.12>.... ... ... .. ... ...... ...... ........ .... ...

123.12 123.12 123.12 123.12 .... ... ... .. ... ...... ...... ........ .... ...

123.12 123.12 123.12 123.12*.... ... ... .. ... ...... ...... ........ .... ...

[15]

123.12 123.12 123.12 123.12 .... ... ... .. ... ...... ...... ........ .... ...

Event: TRIP1 TRIP2 TRIP3 TRIP4 TRIP5

Targets: TRIP INST 87-1 87-2 87-3 50 51 A B C N W1 W2 W3 W4

Winding 1 Currents (A Sec), ABCPQN: 123.4 123.4 123.4 123.4 123.4 123.4

Winding 2 Currents (A Sec), ABCPQN: 123.4 123.4 123.4 123.4 123.4 123.4

Winding 3 Currents (A Sec), ABCPQN: 123.4 123.4 123.4 123.4 123.4 123.4

Winding 4 Currents (A Sec), ABCPQN: 123.4 123.4 123.4 123.4 123.4 123.4

Figure 9.4 Example Differential Event Report

The trigger row includes a > character following immediately after the last

analog column to indicate the trigger point. A

* character following

immediately after the last analog column denotes that the designated row was

used for the Event Summary currents. The

* character takes precedence over

the

> character when both conditions occur for the same row.

Table 9.5 summarizes the event report current columns.

where:

z = Displays results for differential element z (z = 1, 2, or 3)

n = Event number; defaults to 1 if not listed, where 1 is the

most recent event

Sx =Displays x samples per cycle (4 or 8); defaults to 4 if not

listed

Ly =Displays y cycles of data (1 to LER); defaults to LER if

not listed

Ly– = Displays from cycle y to end of report

Ly–w = Displays from cycle y to cycle w
