E.7
Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
Compressed ASCII Commands
SEL-387-0, -5 Relay
The relay responds to the CHI <Enter> command by sending the following:
<STX>
"FID","yyyy"<CR>
"FID=SEL-387-XXXX-V0-ZXXXXXX-DXXXXXXXX","yyyy"<CR>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"REC_NUM","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","EVENT",
"GROUP", "TARGETS", "yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"xxxx",xxxx,"xxxx", "yyyy"<CR>
... (continue previous line until all events are listed -- max 80)
<ETX>
CSTATUS Command
Display the SEL-387 Compressed ASCII status report by sending:
CST <Enter>
The relay sends:
<STX>
"FID","yyyy"<CR>
"FID=SEL-387-XXXX-V0-ZXXXXXX-DXXXXXXXX","yyyy"<CR>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"IAW1","IBW1","ICW1","IAW2","IBW2","ICW2","IAW3","IBW3","ICW3","IAW4",
"IBW4","ICW4","+5V_PS","+5V_REG","-5V_REG","+12V_PS","-12V_PS","+15V_PS",
"-15V_PS","TEMP","RAM","ROM","A/D","CR_RAM","EEPROM","IO_BRD","yyyy"<CR>
"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx",
"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xx
xx", "xxxx","xxxx","yyyy"<CR>
<ETX>
CTARGET Command
Display the SEL-387 Compressed ASCII target display by sending:
CTA N <Enter>
where N is one of the target numbers or element names accepted by the TAR
command. If N is omitted, 0 is used.
where: The data is a list of all events since the last history clear.
xxxx = the data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the hex checksum for
the line.
where:
xxxx = the data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the hex checksum for
the line.
NOTE: If the analog current input
names (IAW1, etc.) have been changed
via the Analog Input Labels global
settings, they will appear in the above
report as set.
