4.46
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Control Logic
Relay Word Bits
RB3 Remote bit RB3 asserted 24
RB4 Remote bit RB4 asserted 24
RB5 Remote bit RB5 asserted 24
RB6 Remote bit RB6 asserted 24
RB7 Remote bit RB7 asserted 24
RB8 Remote bit RB8 asserted 24
RB9 Remote bit RB9 asserted 25
REFP Restricted Earth Fault inverse-time O/C element timed-out 21
RTDINA State of external RTDA module’s digital input
(SEL-387-5 and SEL-387-6 Relays only)
59
RTDINB State of external RTDB module’s digital input
(SEL-387-5 and SEL-387-6 Relays only)
59
RLL Daily rate of loss-of-life alarm asserted
(SEL-387-6 Relay only)
38
S1LT1 Set 1 latch bit S1LT1 asserted 36
S1LT2 Set 1 latch bit S1LT2 asserted 36
S1LT3 Set 1 latch bit S1LT3 asserted 36
S1LT4 Set 1 latch bit S1LT4 asserted 36
S1V1 Set 1 SEL
OGIC control equation
variable S1V1 timer input asserted
32
S1V1T Set 1 SEL
OGIC control equation
variable S1V1 timer output asserted
32
S1V2 Set 1 SEL
OGIC control equation
variable S1V2 timer input asserted
32
S1V2T Set 1 SEL
OGIC control equation
variable S1V2 timer output asserted
32
S1V3 Set 1 SEL
OGIC control equation
variable S1V3 timer input asserted
32
S1V3T Set 1 SEL
OGIC control equation
variable S1V3 timer output asserted
32
S1V4 Set 1 SEL
OGIC control equation
variable S1V4 timer input asserted
32
S1V4T Set 1 SEL
OGIC control equation
variable S1V4 timer output asserted
32
S2LT1 Set 2 latch bit S2LT1 asserted 36
S2LT2 Set 2 latch bit S2LT2 asserted 36
S2LT3 Set 2 latch bit S2LT3 asserted 36
S2LT4 Set 2 latch bit S2LT4 asserted 36
S2V1 Set 2 SEL
OGIC control equation
variable S2V1 timer input asserted
33
S2V1T Set 2 SEL
OGIC control equation
variable S2V1 timer output asserted
33
S2V2 Set 2 SEL
OGIC control equation
variable S2V2 timer input asserted
33
S2V2T Set 2 SEL
OGIC control equation
variable S2V2 timer output asserted
33
Table 4.11 Relay Word Bits Sorted Alphabetically (Sheet 11 of 13)
Bit Definition Row
