6.10

SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601

Setting the Relay

Default Settings

(Continued from previous page)

FAAL1 = 50.00 FAAL2 = 50.00 RLOLL = 50.00 TLOLL = 50.00

CSEP1 = 15

ILIFE = 180000 EDFTC = Y

TDURD = 9.000 CFD = 60.000

TR1 =50P11T + 51P1T + 51Q1T + OC1 + LB3

TR2 =51P2T + 51Q2T + OC2

TR3 =50P31 + 51P3T + OC3

TR4 =87R + 87U

TR5 =0

ULTR1 =!50P13

ULTR2 =!50P23

Press RETURN to continue

ULTR3 =!50P33

ULTR4 =!(50P13 + 50P23 + 50P33)

ULTR5 =0

52A1 =IN101

52A2 =IN102

52A3 =IN103

52A4 =0

CL1 =CC1 + LB4 + /IN104

CL2 =CC2 + /IN105

CL3 =CC3 + /IN106

CL4 =0

ULCL1 =TRIP1 + TRIP4

ULCL2 =TRIP2 + TRIP4

ULCL3 =TRIP3 + TRIP4

ULCL4 =0

ER =/50P11 + /51P1 + /51Q1 + /51P2 + /51Q2 + /51P3

OUT101 =TRIP1

OUT102 =TRIP2

OUT103 =TRIP3

OUT104 =TRIP4

Press RETURN to continue

OUT105 =CLS1

OUT106 =CLS2

OUT107 =CLS3

SCEUSE 46.8

GR1CHK A577

=>>
