Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
SET.31 of 35SEL-387-0, -5, -6 Relay Settings Sheets
Global Settings (SET G Command)
Set Local Bit LB8 Label (7 characters) (Enter NA to Null) SLB8 =
Pulse Local Bit LB8 Label (7 characters) (Enter NA to Null)
PLB8 =
Local Bit LB9 Name (14 characters) (Enter NA to Null)
NLB9 =
Clear Local Bit LB9 Label (7 characters) (Enter NA to Null)
CLB9 =
Set Local Bit LB9 Label (7 characters) (Enter NA to Null)
SLB9 =
Pulse Local Bit LB9 Label (7 characters) (Enter NA to Null)
PLB9 =
Local Bit LB10 Name (14 characters) (Enter NA to Null)
NLB10 =
Clear Local Bit LB10 Label (7 characters) (Enter NA to Null)
CLB10 =
Set Local Bit LB10 Label (7 characters) (Enter NA to Null)
SLB10 =
Pulse Local Bit LB10 Label (7 characters) (Enter NA to Null)
PLB10 =
Local Bit LB11 Name (14 characters) (Enter NA to Null)
NLB11 =
Clear Local Bit LB11 Label (7 characters) (Enter NA to Null)
CLB11 =
Set Local Bit LB11 Label (7 characters) (Enter NA to Null)
SLB11 =
Pulse Local Bit LB11 Label (7 characters) (Enter NA to Null)
PLB11 =
Local Bit LB12 Name (14 characters) (Enter NA to Null)
NLB12 =
Clear Local Bit LB12 Label (7 characters) (Enter NA to Null)
CLB12 =
Set Local Bit LB12 Label (7 characters) (Enter NA to Null)
SLB12 =
Pulse Local Bit LB12 Label (7 characters) (Enter NA to Null)
PLB12 =
Local Bit LB13 Name (14 characters) (Enter NA to Null)
NLB13 =
Clear Local Bit LB13 Label (7 characters) (Enter NA to Null)
CLB13 =
Set Local Bit LB13 Label (7 characters) (Enter NA to Null)
SLB13 =
Pulse Local Bit LB13 Label (7 characters) (Enter NA to Null)
PLB13 =
Local Bit LB14 Name (14 characters) (Enter NA to Null)
NLB14 =
Clear Local Bit LB14 Label (7 characters) (Enter NA to Null)
CLB14 =
Set Local Bit LB14 Label (7 characters) (Enter NA to Null)
SLB14 =
Pulse Local Bit LB14 Label (7 characters) (Enter NA to Null)
PLB14 =
Local Bit LB15 Name (14 characters) (Enter NA to Null)
NLB15 =
Clear Local Bit LB15 Label (7 characters) (Enter NA to Null)
CLB15 =
Set Local Bit LB15 Label (7 characters) (Enter NA to Null)
SLB15 =
Pulse Local Bit LB15 Label (7 characters) (Enter NA to Null)
PLB15 =
Local Bit LB16 Name (14 characters) (Enter NA to Null)
NLB16 =
