D.4

SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601

Configuration, Fast Meter, and Fast Operate Commands

Message Definitions

00CE

494357320000 (ICW2)

00CE

494157330000 (IAW3)

00D2 (Winding 3)

494257330000 (IBW3)

00D2

494357330000 (ICW3)

00D2

494157340000 (IAW4)

00D6 (Winding 4)

494257340000 (IBW4)

00D6

494357340000 (ICW4)

00D6

564443000000 (VDC)

00DA

xx Connection byte–Based on PHROT and W1CT settings

(Calculation block #1)

03 Current calculation only

FFFF No skew adjustment

FFFF No RS offset

FFFF No XS offset

Table D.4 A5C1 Fast Meter Configuration Block (Sheet 2 of 4)
