E.10
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Compressed ASCII Commands
SEL-387-6 Relay
If a Compressed ASCII request is made for data that are not available, (e.g.,
the history buffer is empty or invalid event request), the relay responds with
the following message:
<STX>"No Data Available","0668"<CR><ETX>
CBREAKER Command
Display the SEL-387 Compressed ASCII breaker report by sending:
CBR <Enter>
The relay sends:
<STX>
"FID","yyyy"<CR>
"FID=SEL-387-XXXX-V0-ZXXXXXX-DXXXXXXXX","yyyy"<CR>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"BREAKER","INT_TRIPS","IAW","IBW","ICW","EXT_TRIPS","IAW","IBW","ICW",
"POLE1","POLE2","POLE3","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC",
"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
<ETX>
CEVENT Command
The CEV report contains every analog and digital element found in an EVE
report, and displays the information in Compressed ASCII format by sending:
CEV [DIF R] [n Sx Ly[–[w]] C] <Enter>
where:
yyyy = the 4-byte ASCII representation of the hex checksum for
the line.
#H
identifies a header line to precede one or more data lines,
“#” is the number of subsequent ASCII names. For
example, "21H" identifies a header line with 21 ASCII
labels.
#h
identifies a header line to precede one or more data lines,
“#” is the number of subsequent format fields. For
example, “8h” identifies a header line with 8 format
fields.
#D
identifies a data format line, “#” is the maximum number
of subsequent data lines, each format field contains one of
the following type designators:
I = Integer data
F = Floating point data
mS = String of max “m'”characters (e.g., 10S for a 10-
character string)
NOTE: If the analog current input
names (IAW1, etc.) have been changed
via the Analog Input Labels global
settings, they will appear in the above
report as set.
where: the data consists of a summation of breaker information
collected since the last summary clear.
xxxx = are the data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the hex checksum for
the line.
