5 SCOTTY 5000 PARTS
5.5 PILE FEED DRIVE & TENSIONER
5-13
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--66040 BEARING, BALL 4
2 HW--61050 RING, R ETAINING 5
3
PF--0108 CAM, PILE LIFT 1
HW--52090 SCREW, SET, 1
HW--59030 KEY, SQUARE, 1
4 PF--0107 SHAFT, PILE LIFT CAM 1
5
PF--0114 SPACER, MAIN SLIDE PLATE 3
HW--51480 SCREW,SHC, 6
6
HW--87030 SPROCKET, 1
HW--59030 KEY, SQUARE, 1
7
HW--86040 PULLEY, TIMING GEAR 1
HW--59030 KEY, SQUARE, 1
8
HW--88030 GEAR, BROWNING 1
HW--59030 KEY, SQUARE, 1
9
HW--88020 GEAR, BROWNING 1
HW--59030 KEY, SQUARE, 1
10
HW--86060 PULLEY, TIMING GEAR 1
HW--59030 KEY, SQUARE, 1
11
C--2059 PLATE, TAKE UP 1
HW--53220 SCREW, BUTTON HD., 1
RACE, THRUST 1
12 HW--87020 SPROCKET, 1
13 PF--0109 SHAFT 1
14 HW--85070 NUT, ALLEN 2
15
PF--0157 BAR, TENSION ROLLER MTG. 1
HW--49050 WASHER, FLAT, 2
SCREW, SHC, 2
16
HW--71060 ROLLER, YOKE 1
HW--51520 SCREW, SHC, 1
17 HW--49050 WASHER, FLAT, 1
18 HW--66100 BEARING, BALL, 2
19 HW--51390 SCREW, SHC, 1
20 PF--0156 SPACER 1
21 HW--49110 WASHER, FLAT 1
