5 SCOTTY 5000 PARTS
5.6 PILE FEED - VACUUM BAR DRIVE
5-15
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 PF--0147 SHAFT, VACUUM PICK UP 1
2 PF--0140 PIPE, VACUUM CONNECTION 1
3
PF--0198 ARM, NOZZLE LIFT RH. 1
HW--57200 PIN, SPRING, 1
HW--51240 SCREW, SHC., 2
4
PF--0217 SHAFT, VACUUM BAR PIVOT 1
HW--63100 FITTING, GREASE, 1
5 HW--72030 ROLLER, CLUTCH 2
6
PF--0143 BLOCK, VACUUM, CONNECTION 1
HW--51240 SCREW, SHC., 2
7 HW--63300 CONNECTOR, MALE, 1
8
PF--0150 ARM, VACUUM PICK UP 1
HW--51210 SCREW,SHC, 2
HW--57180 PIN, SPRING, 2
9 PF--0160 BLOCK, SPACER 1
10
ROD END, MALE 1
HW--51470 SCREW, SHC., 1
HW--60230 NUT,NYLONINSERT, 1
HW--49060 WASHER, SAE, 3
11
PF--0161 SIDE, PLATE 2
HW--51190 SCREW, SHC, 8
12 PF--0162 BLOCK, SPACER 1
13
HW--70030 ROD END, FEMALE 1
HW--60130 NUT,JAM, 1
PF--0163 CONNECTING ROD 1
HW--60210 NUT,NYLONINSERT, 1
HW--51380 SCREW, SHC., 1
HW--49050 WASHER, SAE 3
14 PF--0136 RING, VACUUM CONNECTION 1
15 PF--0137 RING, VACUUM CONNECTION 1
16 HW--66160 BEARING, BALL 2
17 HW--61050 RING, RETAINING 3
18 PF--0134 SHAFT, VACUUM BAR DRIVE 1
19
PF--0146 ARM, NOZZLE LIFT LH. 1
HW--57200 PIN, SPRING, 1
HW--51240 S C R E W , S H C . , 2
20
PF--0216 RING, SLIP CLUTCH PLATE MTG. 1
HW--52090 SCREW, SHC., 1
HW--84020 BALL, NYLON, 1
HW--57080 PIN, SPRING, 2
21 PF--0139 PLATE, SLIP CLUTCH 1
22 PF--0138 CLUTCH PLATE 1
23
PF--8605--A PULLEY, GEAR BELT 1
HW--79060 SPRING, COMPRESSION 2
HW--57090 PIN, SPRING, 2
24 HW--66040 BEARING, BALL 1
25
HW--60250 NU T, N YLO N I N SE RT, 1
HW--63120 FITTING, GREASE, 1
26 HW--61040 RING, RETAINING 1
27 PF--8607--A PULLEY, GEAR BELT 1
28 PF--0223 SPACER, BEARING 1
29 HW--66020 BEARING, BALL 2
30
PF--8606--A PULLEY, GEAR BELT 1
SCREW, SHC, 2
31 PF--0145 SHAFT, IDLER 1
32 HW--69220 THRUST, RACE 2
33 HW--66050 BEARING, BALL 2
34 HW--61220 RING, RETAINING 3
35 HW--74030 O--RING, PARKER 3
36 PF--0141 BLOCK, VACUUM CONNECTION 1
37 PF--0142 PIPE, VACUUM CONNECTION 1
38 HW--57170 PIN, SPRING, 1
