100
RF Specification:
WiFi Module 802C2447
Function Operation Frequency Max RF output power Limit
5.2G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ ac20:
5180~5240MHz;
802.11n40/ ac40: 5190~5230MHz;
802.11 ac80: 5210MHz;
802.11a: ANT 0: 22.20dBm; ANT 1:
22.40dBm; ANT 2: 22.60dBm
802.11n20: ANT 0: 22.80dBm; ANT 1:
22.90dBm; ANT 2: 22.80dBm
802.11n20: ANT 0: 22.80dBm; ANT 1:
22.90dBm; ANT 2: 22.80dBm
802.11n40: ANT 0: 22.90dBm; ANT 1:
22.70dBm; ANT 2: 22.90dBm
802.11ac40: ANT 0: 22.70dBm; ANT 1:
22.70dBm; ANT 2: 22.90dBm
802.11ac80: ANT 0: 22.90dBm; ANT 1:
22.80dBm; ANT 2: 22.70dBm
23 dBm.
5.8G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ac20: 5745-5825 MHz
802.11n40/ac40: 5755-5795 MHz
802.11 ac80: 5775MHz
802.11a: ANT 0: 13.60dBm; ANT 1:
13.90dBm; ANT 2: 13.80dBm
802.11n20 MIMO: 13.96dBm;
802.11ac20 MIMO: 13.96dBm;
802.11n40 MIMO: 13.90dBm;
802.11ac40 MIMO: 13.90dBm;
802.11ac80 MIMO: 13.92dBm;
13.98dBm
Function Operation Frequency Max RF output power Limit
BLE 2402~2480 MHz -0.31 dBm. 20 dBm.
