101
WiFi Module 802R8822
Function Operation Frequency Max RF output power Limit
2.4G WIFI
802.11b/g/n
(HT20,HT40)
802.11b/g/n(20MHz):
2412~2472MHz;
802.11n(40MHz): 2422~2462MHz
802.11b: ANT A: 18.20dBm; ANT B: 18.30dBm
802.11g: ANT A: 19.90dBm; ANT B: 19.90dBm
802.11n20MIMO:19.96dBm;
802.11n40MIMO:19.98dBm;
20 dBm.
5.2G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ ac20:
5180~5240MHz;
802.11n40/ ac40: 5190~5230MHz;
802.11 ac80: 5210MHz;
802.11a: ANT A: 22.50dBm; ANT B: 21.80dBm
802.11n20 MIMO: 22.50dBm;
802.11ac20 MIMO: 22.5dBm;
802.11n40 MIMO: 22.93dBm;
802.11ac40 MIMO: 22.93dBm;
802.11ac80 MIMO: 22.77dBm;
23 dBm.
5.3G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ ac20:
5260~5320MHz;
802.11n40/ ac40: 5270~5310MHz;
802.11 ac80: 5290MHz;
802.11a: ANT A: 21.70dBm; ANT B: 21.00dBm
802.11n20 MIMO: 21.97dBm;
802.11ac20 MIMO: 21.97dBm;
802.11n40 MIMO: 22.97dBm;
802.11ac40 MIMO: 22.97dBm;
802.11ac80 MIMO: 22.98dBm;
23dBm
5.6G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ ac20:
5500~5700MHz;
802.11n40/ ac40: 5510~5670MHz;
802.11 ac80: 5530~5610MHz;
802.11a: ANT A: 22.40dBm; ANT B: 22.20dBm
802.11n20 MIMO: 22.36dBm;
802.11ac20 MIMO: 22.36dBm;
802.11n40 MIMO: 22.95dBm;
802.11ac40 MIMO: 22.95dBm;
802.11ac80 MIMO: 22.93dBm;
23dBm
5.8G WIFI
802.11a/ac(HT20,
HT40,HT80)
/n(HT20,HT40)
802.11a/n20/ac20: 5745-5825 MHz
802.11n40/ac40: 5755-5795 MHz
802.11 ac80: 5775MHz
802.11a: ANT A: 13.90dBm;ANT B: 13.90dBm
802.11n20 MIMO: 13.96dBm;
802.11ac20 MIMO: 13.96dBm;
802.11n40 MIMO: 13.93dBm;
802.11ac40 MIMO: 13.96dBm;
802.11ac80 MIMO: 13.96dBm;
13.98dBm
