Sekonic SPECTROMASTER C-800 User Manual

7
2. Before Use
NOTICE
●
When the Light Selection Ring
2
is not set to the dark
calibration position, the message "Please set Light
Selection Ring for dark calibration." is displayed. Set the
Light Selection Ring
2
to the dark calibration position
( ) to calibrate the system.
●
If dark calibration is not successful, "Dark calibration
failed. Please check Light Selection Ring position." is
displayed. Set the Light Selection Ring
2
to the dark
calibration position ( ) to calibrate the system.
6.
Press the Measuring Button 5 to measure.
Turn the Light Selection Ring
2
to select the range.
When measuring ambient light, make sure to select Range L ( ).
When measuring ash units, select Range L ( ) or Range H ( )
depending on the brightness of of the ash. (

P99,

P101)
NOTICE
When the Measuring Button
5
is pressed at the dark calibration
position, the message "Measurement failed. Please check Light
Selection Ring position." is displayed. Set the Light Selection Ring
2
to the correct position and the Measuring screen will be displayed.
Dark Calibration Position
Conrmation Screen
Dark Calibration
Conrmation Screen

Sekonic SPECTROMASTER C-800 Specifications

General

Type	Spectrometer
Color Temperature Range	1, 600 to 40, 000 K
Spectral Wavelength Range	380 to 780 nm
Power Source	Rechargeable lithium-ion battery
Operating Temperature	0 to 40°C (32 to 104°F)
Display	Color LCD
Measurement Range	1 to 200, 000 lx
Spectral Response	Human eye response
Connectivity	USB
Weight	350 g (including battery)
Memory Capacity	Up to 1, 000 measurements
