Sensus SensusRF - DC Power Specification

11
SensusRF gateway user manual
| 29/10/2019
Model 300.128
Model 132.0028.03
IMPORTANT
The DC input terminal connector is rotated 180 degrees between the two DC power supply versions.
5.2.1 DC power Specification
Model
300.128
Model
132.0028.03
DC INPUT voltage
12-24 V DC
DC INPUT voltage
12-24 V DC
DC INPUT current(*)
350mA@12V DC
180mA@24V DC
DC INPUT current(*)
350mA@12V DC
180mA@24V DC
Output Voltage
6.5V
Output Voltage
6.5V
Output Current (Max)
2A
Output Current (Max)
3A
Output Power (Max)
13.7W
Output Power (Max)
19.5W
(*) DC INPUT current is related to the product average power consumption, not to power supply maximum
output power.
DC INPUT
Ground (-V)
DC INPUT (+V)
DC INPUT
Ground (-V)
DC INPUT (+V)
